MX5068镂铣床
主要应用：可安装各种镂铣刀具，对哪个好板材进行倒角、修边、仿形等加工
其他应用：木工、铝材等材料的修边加工
|
技术参数 |
|
外形尺寸: |
1450x800xl7OOmm |
|
工作台规格: |
800x600mm |
|
工作台升降行程: |
180mm |
|
最大工件厚度: |
150mm |
|
主车由最大行程: |
65mm |
|
主车由至立柱距离: |
730mm |
|
刀类直径: |
06.3-12.7mm |
|
主车由转速: |
18000 r/min |
|
整机功率: |
3KW |
|
吸尘口: |
070mm |
|
工作气压: |
0.6Mpa |
|
整机重量: |
410kg |
|
供电要求: |
3相380V 10A |
可选：根据不同的应用可选择工作方式为气动升降或脚踩升降的
接受非标定制，为个性化的应用单独设计
MX5068 High Speed Copy Router
Main applications: You can install various fingerskrouters tool of acrylic sheet chamfering, trimming, copying and other processing
Other applications: Trimming and machining of wood, aluminum and other materials
Technical parameter:
|
Outline dimension: |
1450x800x1700mm |
|
Table specification: |
800x600mm |
|
Working Table Lift Stroke: |
180mm |
|
Max.WorkpieceThichness: |
150mm |
|
Spindle Max. Stroke: |
65mm |
|
Distance Between Spindle |
|
|
And slang Column: |
730mm |
|
Tool Holder Dia |
Ф6.3-12.7mm |
|
Speed of mainshaft |
18000 r/min |
|
Power of the whole machine |
3KW |
|
Dust Exit |
Ф70mm |
|
Air Consumption |
0.6Mpa |
|
Net Weight |
410kg |
|
Power supply requirements: |
3 phase 10A 380VN |
Optional assembly: According to different applications can choose the way of working for pneumatic lifting or lifting the foot
Accept non-standard custom，Designed to your specific
